Width Gauge PG-005 - High precision carbide measurement tool
Width Gauge front view
Width Gauge side view
Width Gauge technical diagram
Width Gauge measurement setup

Technical Diagram

Ø 10.000 ±0.001mm Length: 50mm PG-001

Width Gauge PG-005

High-Precision Carbide Width Gauge

In Stock SKU: PG-001-10.000

Precision-engineered carbide width are precision measuring tools used to measure the width of grooves, slots, or components with extremely high accuracy. Manufactured to the highest standards with NABL calibration certificate included.

Key Specifications

Nominal Diameter 10.000 mm
Tolerance ±0.001 mm
Length 50 mm
Material Tungsten Carbide
Surface Finish Ra 0.1 μm
Accuracy Grade Grade 0

Material Composition

Tungsten Carbide (WC) 94%
Cobalt Binder (Co) 6%

Hardness: 1500-1800 HV | Density: 14.5-15.0 g/cm³

Share Specifications

Dimensional Specifications

Parameter Value Tolerance
Nominal Diameter 10.000 mm ±0.001 mm
Length 50.0 mm ±0.05 mm
Roundness 0.0005 mm Max
Straightness 0.001 mm Max
Surface Roughness Ra 0.1 μm Max

CMC Values

Range (mm) Uncertainty (μm) k=2
1 to 10 0.3 95%
10 to 25 0.4 95%
25 to 50 0.5 95%

Note: CMC values are valid under controlled laboratory conditions at 20°C ± 1°C

Product Inquiry

Get detailed information about Pin Gauge PG-001 or request a custom quote

Contact Us Directly
